VFFS Equipment Manufacturers Timing Belt Matching Table
Home / VFFS Equipment Manufacturers
Our Advantage
We don’t just list belt models—we precisely match each belt to your specific VFFS equipment. All recommended timing belts and conveyor belts are tailored to the unique working conditions, speed, load, and packaging scenarios of each brand’s equipment. They can be directly used as original replacement parts, ensuring stable operation and long service life. We also offer food-grade options (FDA certified) and special customization (oil-resistant, anti-static, high-temperature resistant) to meet your personalized needs. For high-speed VFFS models, we specially recommend arc-tooth timing belts (HTD/AT series) for higher transmission accuracy and lower noise, all based on precise equipment parameter matching.
| Brand Group | Sub-brand | Typical VFFS Models | Belt Application Position | Recommended Timing Belt Model | Recommended Conveyor Belt Model | Remarks |
|---|---|---|---|---|---|---|
| ProMach | Matrix | MVI‑280, MVI‑330, MVX‑200, Apollo, Morpheus | Film Unwinding System, Longitudinal Sealing Drive, Transverse Sealing Drive, Feeding Transmission | HTD 5M‑20mm, AT5‑15mm, T5‑25mm | PU Flat Conveyor Belt 2.0mm, PU Pattern Conveyor Belt 1.5mm | High-speed model ≥150 packs/min; FDA certification required for food-grade applications |
| ProMach | Oden 900, 1100, 1400 Series | Film Traction, Transverse Sealing Opening/Closing, Discharge Conveying | HTD 3M‑15mm, AT10‑25mm | PU Flat Belt 2.0mm, Oil-resistant Conveyor Belt 2.5mm | Hygienic design, IP65, easy to clean | |
| ProMach | VFFS Continuous/Intermittent Series | Film Unwinding System, Transverse Sealing Drive, Tension Pulley | HTD 5M‑20mm, T10‑30mm | PU Food-grade Conveyor Belt 2.0mm | High-temperature and oil-resistant, suitable for cooked food packaging | |
| Haver & Boecker | VFS Series, Roto‑Pack Series | Film Unwinding, Measuring Feeding, Transverse Sealing, Finished Product Conveying | AT5‑20mm, HTD 8M‑25mm | PU Wear-resistant Conveyor Belt 2.5mm, Anti-slip Conveyor Belt | Specialized for bulk powder/granules, high load-bearing | |
| PAXION | VFS Series, Flowmodul Series | Film Unwinding Servo Transmission, Longitudinal Sealing, Transverse Sealing Drive | HTD 5M‑15mm, AT5‑20mm | PU Flat Belt 2.0mm, Anti-static Conveyor Belt 1.5mm | High-speed continuous type, high positioning accuracy | |
| Triangle Package Machinery | XYTLF, Sanitary VFFS Series | Film Unwinding System, Transverse Sealing Drive, Discharge Conveying | HTD 5M‑20mm, T5‑25mm | PU Food-grade Conveyor Belt 2.0mm, Easy-to-clean Type | IP69K, washable, FDA/USDA certified | |
| Berkman | VFFS Standard/High-speed Series | Film Traction, Transverse Sealing, Finished Product Output | HTD 3M‑15mm, AT5‑20mm | PU Flat Conveyor Belt 2.0mm, Lightweight Conveyor Belt 1.5mm | Small and medium-sized packaging machines, low noise, high precision | |
| Bosch Packaging (now Syntegon) | SVE Series, SVH Series, CM Series | Film Unwinding Servo Drive, Transverse/Longitudinal Sealing Transmission, Finished Product Conveying Section, Tension Mechanism | HTD 5M‑20mm, AT10‑25mm, T10-610 | PU Food-grade Conveyor Belt 2.0mm, Wear-resistant PU Pattern Belt 2.5mm | Suitable for high-speed models (≤200 packs/min), FDA available for food-grade, anti-static required for some models, compatible with continuous/intermittent equipment | |
| SACMI | FFS Series, Dairy FFS Special Series | Film Traction, Measuring Feeding Transmission, Transverse Sealing Drive, Finished Product Output | HTD 8M‑25mm, AT5‑20mm, T10-560 | Oil-resistant PU Conveyor Belt 2.5mm, PU Food-grade Flat Belt 2.0mm | Focus on dairy packaging, hygienic design, temperature resistance ≤120℃, acid and alkali resistant customization available, suitable for powder/granule packaging | |
| IMA Group | FLX Series, VFFS Continuous/Intermittent Series | Film Unwinding System, Longitudinal Sealing Drive, Transverse Sealing Opening/Closing, Finished Product Inspection Conveying | HTD 5M‑20mm, AT5‑15mm, 345L-25 | PU Flat Conveyor Belt 2.0mm, Anti-static Lightweight Conveyor Belt 1.5mm | Suitable for food/pharmaceutical packaging, high positioning accuracy, supports multiple bag types, IP67 protection required for some models | |
| ROVI (ROVEMA) | BV CORE 260, VP Series, R-Series | Film Traction, Transverse Sealing Drive, Feeding Transmission, Finished Product Conveying | HTD 5M‑20mm, AT10‑25mm, T10-720 | PU Wear-resistant Conveyor Belt 2.5mm, Anti-slip Pattern Conveyor Belt 2.0mm | Cost-effective, suitable for medium-high speed packaging (≤180 packs/min), modular design, easy maintenance | |
| TNA | robag® TX Series, VFFS High-speed Series | Film Vacuum Traction, Transverse Sealing Drive, Finished Product Conveying, Servo Transmission Mechanism | HTD 3M‑15mm, AT5‑20mm, T10-920 | PU Food-grade Flat Belt 2.0mm, Lightweight Anti-static Conveyor Belt 1.5mm | Ultra-high speed model (≤250 packs/min), low waste rate, suitable for snack food/powder packaging, wear-resistant timing belt required | |
| GHD Hartmann | VFFS Standard Series, High-speed Custom Series | Film Unwinding System, Transverse/Longitudinal Sealing Drive, Tension Pulley, Finished Product Output | HTD 5M‑20mm, T5‑25mm, AT5-20mm | PU Flat Conveyor Belt 2.0mm, Oil-resistant Conveyor Belt 2.5mm | Suitable for small and medium-sized production lines, low noise, custom special length timing belts available, FDA food-grade option supported | |
| Severin | VFFS Small Series, Semi-automatic VFFS Series | Film Traction, Transverse Sealing Drive, Simple Finished Product Conveying | HTD 3M‑15mm, T5‑20mm, T10-630 | Lightweight PU Flat Belt 1.5mm, Ordinary PU Conveyor Belt 2.0mm | Focus on small packaging scenarios, low load, easy to install and replace, cost-effective, suitable for low-speed packaging needs | |
| Toyo Machinery & Metal (Toyo) | GTH Series, GTY Series, ECH Series | Film Unwinding Servo Transmission, Transverse/Longitudinal Sealing Drive, Finished Product Conveying, Tension Mechanism | HTD 5M‑20mm, AT5‑20mm, T10-720 | PU Wear-resistant Conveyor Belt 2.5mm, PU Food-grade Flat Belt 2.0mm | Japanese original technology, suitable for medium-high speed packaging (≤160 packs/min), high temperature and oil resistant, custom special tooth timing belts available | |
| Fuji Machinery (Fuji) | FFS100, FFS200 Series, Fuji-Topak FFS Series | Film Traction, Multi-section Storage Conveying, Transverse Sealing Drive, Feeding Transmission | HTD 3M‑15mm, AT5‑20mm, T5‑25mm | PU Pattern Conveyor Belt 2.0mm, Lightweight Anti-static Conveyor Belt 1.5mm | Servo feeding design, belts easy to disassemble and clean, suitable for food/electronic component packaging, low noise operation | |
| CKD Corporation | VFFS Intermittent Series, CKD-VFS Small Series | Film Unwinding System, Longitudinal Sealing Drive, Tension Pulley, Simple Finished Product Conveying | HTD 5M‑15mm, T5‑20mm, AT5-15mm | PU Flat Conveyor Belt 2.0mm, Oil-resistant Lightweight Conveyor Belt 1.5mm | Japanese precision transmission, suitable for small production lines, high positioning accuracy, FDA food-grade option supported, easy maintenance | |
| KHS (Japanese Joint Venture) | KHS-VFFS 300, 500 Series | Film Traction, Transverse Sealing Drive, Finished Product Inspection Conveying, Feeding Transmission | HTD 8M‑25mm, AT10‑25mm, T10-610 | PU Wear-resistant Conveyor Belt 2.5mm, Anti-slip Pattern Belt 2.0mm | Joint venture technology, high load-bearing capacity, oil and high temperature resistant, suitable for beverage and powder packaging, IP65 protection required for some models |
